- Capacity
: 1000 – 5000 IG - Application
: For transportation of Sewage water, Treated water, etc. - Shape
: Cylindrical with outer rings for stiffening - Construction
: All welded steel construction - Steel - SA 36/ST 52-3/Equivalent steel - Electricals
: 7 pin - 24V – Side lights, Reflectors, Reverse lights - Pump
: PTO driven vacuum pump - Door
: Full open type – With hinges at driver side at rear – Secured with set of clamps- Sealed with neoprene rubber – Provision of greasing for clamp lubrication
- Safety Equipment : Pressure & Vacuum relief valve – To control pressure and vacuum inside tank
- Primary & Secondary cut off – To prevent water entering inside pump
- Combination gauge – Showing pressure and vacuum inside tank
- Accessories : Level Indicator – Slight glass – Showing level of content inside tank
- Optional 20” inspection man way
- Spare wheel carrier to accommodate spare tire
- Side & Rear anti run bumper
- Mudguards & Mud flaps
- Tool box & GRP Water tank
- Hose box with fill & discharge hoses – On either side of the tank
- Finish : Internal A. Grit blasting – SA 2.5
- B. Epoxy / Coal tar coating – Two coats
- External A. Grit blasting - SA 2.5
- B. Epoxy primer followed by two coat of paint
