- Capacity
: 300 BBL - 500 BBL - Shape
: Rectangular with - A. Bottom round & top flat, B. Bottom & Top round, C. Bottom “V” & top flat - Compartment
: Single or Multiple compartment - Application
: Suitable for Slurry, Water, HCL (Up to 32% concentration), Crude oil and other chemicals. - Construction
: Steel - SA 36, 516 Gr.70, ST 52-3, Equivalent steel- Axle – 12/15 Ton – Mechanical suspension – Under slung
- Tires – 11
R 22.5 Brake – Two line air brake system, Spring assisted brakes
- Pipe lines : Fill line – With Valves & Hammering unions – One or Two – As per client requirements
- Discharge Manifold (6”/8”/10”) – 2-4 number of outlets – With Valves & Hammering unions
- Vent line – One number per compartment - With Valves & Hammering unions
- Drain line - One number per compartment - With Valves & Hammering unions
- Man ways : Minimum 2 numbers – One at bottom and one at top for easy accessibility
- Level Indicator : PVC dipstick with maple wood
- Sight glass – Magnetic level indicator
- Internal Coating : Epoxy primer, Coal tar epoxy for Water & Slurry application
- Derakane or Rubber lining for HCL and other highly corrosive chemicals
- External Finish : Grit blasting followed by three coat paint system
