- Capacity
: Single Silo - 750 – 3500 CFT- Twin silo – 2 X 1000 CFT
- Type
: U-stamp, Non U-stamp- Gravity discharge, Under pressure discharge
- Application
: Storage of Cement, Barite, Bentonite,etc - Construction
: Steel - SA 36, 516 Gr.70, ST 52-3, Equivalent steel Pipe lines : Fill / Vent / Discharge line – Terminated with Valves & Hammering unions/CustomizedAeration system with Air jets / Aeration pad
Man ways: At bottom – For easy accessibility – Optional man way at top- Testing/Inspection
: Tank weld joints – MPI / Radiography – As per client requirements- Lifting lugs - Load test – MPI testing - Certified for empty lift - Witnessed by qualified third party
- Hydro test – As per working pressure – Witnessed by qualified third party
- Accessories
: Pressure relief valve- Pressure gauge
- Ladder with bolted cage
- Provision for mounting compression load cell
- External Finish : Grit blasting followed by three coat paint system
