- Capacity
: 20 – 60 CBM - Certification
: U-stamp. Non U-stamp - Construction
: Steel - SA 36, 516 Gr.70, ST 52-3, Equivalent steel- Axle – Tandem / Trident axle – Mechanical suspension
- Tires – Suitable for load / terrain condition
Brake – Two line air brake system, Spring assisted brakes- King pin – 2” – JOST – Interchangeable with 3.5”
- Landing Leg – JOST - 2 Speed
- Electricals – 7 pin - 24V – Side lights, Reflectors, Reverse lights
Pipe lines : Fill / Vent / Discharge line – Terminated with Valves & Hammering unions/CustomizedAeration system with Air jets / Aeration pad
- Man ways : One number on each silo – At top for easy accessibility • Compressor : Air compressor – Piston type – With Deutz diesel engine
- Aeration System : Jet or pad system
- Testing/Inspection : Tank weld joints – MPI / Radiography – As per client requirements
- Lifting lugs - Load test – MPI testing - Certified for empty lift - Witnessed by qualified third party
- Hydro test – As per working pressure – Witnessed by qualified third party
- External Finish : Grit blasting followed by three coat paint system
