- Capacity
: 6000 – 12000 IG - Shape
: Elliptical, Double-D or Customized • Compartment: Single or Multiple compartment - Application
: For transportation of Diesel, Petrol, Crude oil etc. - Construction
: Steel - SA 36/ST 52-3/Stainless Steel/Aluminum/Equivalent steel- Axle – Tandem/Trident – Mechanical/Air suspension – Under slung/Over slung
- Tires – Subject to Load/Terrain
Brake – Two line air brake system, Optional ABS/EBS/Emergency/Spring assisted brakes
Pipe lines : Top or Bottom loading- Fill line – Customized as per client requirements - With Valves & Unions
- Discharge line - Customized as per client requirements - With Valves & Unions
- Vapor Recovery line – Optional
- Man ways : Quantity as per number of compartment for easy accessibility
- Safety devices : Pressure & Vacuum relief valves
- Optical sensor to avoid spill over
- Emergency shut off
- Vent line & Spill over tray connected to optional scrubber tank
- Optional tanker over turn protection
- Level Indicator : PVC/Aluminum dipstick
- Sight glass – Magnetic level indicator
- Internal Coating : Epoxy primer/Diesel wash
- External Finish : Grit blasting followed by three coat paint system
