- Capacity
: 5 – 22 CBM - Application
: For transportation of Dry sand, Aggregate, Rocks, Other commodities - Shape
: Box type / Taper Door / Half pipe / Scow end - Construction
: - A.
Sand Application:-- All welded steel construction - Steel - SA 36/ST 52-3, Equivalent steel
- Door: Automatic opening/closing with claw lock mechanism
: - B. Rock application:- All welded steel construction – Steel for tipper is Hardox – 450 Welded angles all over inside body to take care of rock impact load
- Door : Scow end door with chain mechanism
- : Front end hydraulic jack / Under body jack
- Electricals – 7 pin - 24V – Side lights, Reflectors
- Accessories : Spare wheel carrier to accommodate two spare tires : Side & Rear anti run bumper : Mudguards & Mud flaps : Tool box & GRP Water tank
- Finish : Grit blasting followed by three coat paint system
