- Capacity
: Body = 5 – 22 CBM- Bin/Hopper = 80/120/240 Liters
- • Application
: For transportation/compaction of waste material size - • Construction
: All welded steel construction - Steel - SA 36/ST 52-3/Equivalent steel - • Compaction
: Garbage taken inside body via sweeper shovel-actuated by two double actinghyd cylinders- Garbage pushed into the body by two double acting sledge cylinders
- • Lifting
: Tail gate raiseachieved by two double acting cylinders- Equipped with safety device to prevent tail
gate falling abruptly in case of hose burst/failure
- Equipped with safety device to prevent tail
- Electricals : 7 pin - 24V – Side lights, Reflectors
- • Pump : Diesel or Petrol Engine driven – Mounted on chassis
- PTO driven pump
- • Accessories : Spare wheel carrier to accommodate spare tire
- Side & Rear anti run bumper
- Mudguards & Mud flaps
- Tool box & GRP Water tank
- Hose box with fill & discharge hoses – On either side of the tank
- Finish : Internal
- A. Grit blasting – SA 2.5
- B. Epoxy coating – Two coats – To suit content
- External A. Grit blasting - SA 2.5
- B. Epoxy primer followed by two coat of paint
