- Capacity
: 20 – 60 CBM - Application
: For transportation of Dry sand, Aggregate, Rocks, Other commodities - Shape
: Box type / Taper Door / Half pipe / Scow end - Construction
: A.Sand Application:-- All welded steel construction - Steel - SA 36/ST 52-3, Equivalent steel Door
- Automatic opening/closing with claw lock mechanism
- B. Rock application:-
- All welded steel construction – Steel for TIPPER is Hardox – 450
- Welded angles all over inside body to take care of rock impact load
- Door: Scow end door with chain mechanism
- Front end hydraulic jack – 80/100 Ton
- Axle – Multi leaf Mechanical suspension – 3X16/18 Ton
- Tires – Twin tire fitment - As per Load/Terrain condition
- Brakes – Two line air brake system – Acting on all wheels – Automatic load sensing valve
- Landing gear – Two speed – Manual : King pin – 2” or 3.5” – Interchangeable
- Electricals – 7 pin - 24V – Side lights, Reflectors, Reverse lights
- Accessories : Spare wheel carrier to accommodate two spare tires
- Side & Rear anti run bumper
- Mudguards & Mud flaps
- Tool box & GRP Water tank
- Finish : Grit blasting followed by three coat paint system
