- Capacity
: 25 – 60 CBM - Application
: For transportation of Dry sand, Aggregate, Rocks, Other commodities - Shape
: V / Banana type self-supporting body - Construction
: All steel welded construction – Steel A 36/ST 52-3/Equivalent- Designed to operate under working pressure of above 2 Bar
- Both ends of the tank are dished
: Aeration system – Canvas hose with aluminum strip - Safety accessories – Pressure relief valve, Pressure gauge, Non return valve,
- Discharge – Both
side of the tank with air hoses, shut off valves - Man way at the top – 20”
: Walk way on the top withfoldable hand rail - Axle – Multi leaf Mechanical/Air suspension – Tandem/Trident
- Tires – Twin tire fitment - As per Load/Terrain condition
- Brakes – Two line air brake system – Acting on all wheels – Automatic load sensing valve
- Landing gear – Two speed – Manual
- King pin – 2” or 3.5” – Interchangeable
- Electricals – 7 pin - 24V – Side lights, Reflectors, Reverse lights
- Compressor : Air compressor – Piston type – With Deutz diesel engine
- Accessories : Discharge hoses – Steel wired : Spare wheel carrier : Rear anti run bumper : Mudguards & Mud flaps : Tool box & GRP Water tank
- Finish : Grit blasting followed by three coat paint system
